Triangle Pillow Block Bearing Types
Triangle Manufacturing offers a wide variety of pillow block bearing types. You can find a pillow block bearing from Triangle if you have a light or heavy-duty application.
Miniature Pillow Block Bearings
Triangle's miniature pillow block bearings are stamped from 16-gauge galvanized steel. They are manufactured a sintered bronze, sintered iron or molded nylon spherical plain bearing.
Applications for Triangle's Miniature Pillow Block Bearings include:
- Vending Machines
- Food Processing Equipment
- Small Conveyors
- Rock Tumblers
- Skid Steer Foot Controls
Shaft Size | Molded Nylon | Sintered Bronze | Sintered Iron |
1/4" | BDN4 | BD1404P* | BD1504P* |
5/16" | BDN5 | BD1405P* | BD1505P* |
3/8" | BDN6 | BD1406P | BD1506P* |
7/16" | BDN7 | BD1407P* | BD1507P* |
1/2" | BDN8 | BD1408P | BD1508P |
5/8" | BDN10 | BD1410P | BD1510P |
3/4" | BDN12 | BD1412P* | BD1512P |
*These pillow block bearings are not available on our website. Please contact us if you would like to learn more information.
Medium Duty Pillow Block Bearings
Triangle's medium duty pillow block bearings are stamped from 16-gauge galvanized steel. They are manufactured with a H series or E series spherical plain bearing. They can come with an oil cup or grease fitting.
Applications for Triangle's Medium Duty Pillow Block Bearings Include:
- Hose Reels
- Agriculture Equipment
- Food Processing Equipment
- Rock Tumblers
Oil Cup | Grease Fitting | Shaft Size | A | B | C | D |
BBH8A | BBH8G | 1/2" | 1.75" | 0.906" | 3.938" | 2.875" |
BBH10A | BBH10G | 5/8" | 1.75" | 0.906" | 3.938" | 2.875" |
BBH12A | BBH12G | 3/4" | 1.75" | 0.906" | 3.938" | 2.875" |
BBH14A | BBH14G | 7/8" | 1.75" | 0.906" | 3.938" | 2.875" |
BCE12A | BCE12G | 3/4" | 2.063" | 1.063" | 4.562" | 3.313" |
BCE13A | BCE13G | 13/16" | 2.063" | 1.063" | 4.562" | 3.313" |
BCE14A | BCE14G | 7/8" | 2.063" | 1.063" | 4.562" | 3.313" |
BCE15A | BCE15G | 15/16" | 2.063" | 1.063" | 4.562" | 3.313" |
BCE16A | BCE16G | 1" | 2.063" | 1.063" | 4.562" | 3.313" |
BCE18A | BCE18G | 1 1/8" | 2.063" | 1.063" | 4.562" | 3.313" |
BCE19A | BCE19G | 1 3/16" | 2.063" | 1.063" | 4.562" | 3.313" |
BCE20A | BCE20G | 1 1/4" | 2.063" | 1.063" | 4.562" | 3.313" |
Extra Strength Pillow Block Bearings
Triangle's extra strength pillow block bearings are stamped from 13-gauge cold rolled steel. They are manufactured with a H series or E series spherical plain bearing. They can come with an oil cup or grease fitting.
Applications for Triangle's Extra Strength Pillow Blocks Include:
- Manufacturing Process Equipment
- Stadium Seating
- Conveyors
- Treadmills
Oil Cup | Grease Fitting | Shaft Size | A | B | C | D |
BEH8A | BEH8G | 1/2" | 1.819" | 0.938" | 4.032" | 2.969" |
BEH10A | BEH10G | 5/8" | 1.819" | 0.938" | 4.032" | 2.969" |
BEH12A | BEH12G | 3/4" | 1.819" | 0.938" | 4.032" | 2.969" |
BEH14A | BEH14G | 7/8" | 1.819" | 0.938" | 4.032" | 2.969" |
BEH16A | BEH16G | 1" | 1.819" | 0.938" | 4.032" | 2.969" |
BFE12A | BFE12G | 3/4" | 2.188" | 1.094" | 4.625" | 3.328" |
BFE13A | BFE13G | 13/16" | 2.188" | 1.094" | 4.625" | 3.328" |
BFE14A | BFE14G | 7/8" | 2.188" | 1.094" | 4.625" | 3.328" |
BFE15A | BFE15G | 15/16" | 2.188" | 1.094" | 4.625" | 3.328" |
BFE16A | BFE16G | 1" | 2.188" | 1.094" | 4.625" | 3.328" |
BFE18A | BFE18G | 1 1/8" | 2.188" | 1.094" | 4.625" | 3.328" |
BFE19A | BFE19G | 1 3/16" | 2.188" | 1.094" | 4.625" | 3.328" |
BFE20A | BFE20G | 1 1/4" | 2.188" | 1.094" | 4.625" | 3.328" |
Heavy Duty Pillow Block Bearings
Triangle's heavy-duty pillow block bearings are stamped from 11-gauge galvanized steel. The strength of these pillow block bearing mounts are comparable to competitor cast iron pillow block mounts. These bearings can be manufactured with Triangle's E series and F series spherical plain bearings. They can also be manufactured with a cast-iron spherical plain bearing.
Applications for Triangle's Heavy-Duty Pillow Block Bearings Include:
- Manufacturing Process Equipment
- Reels
- Dump Trucks
- Evaporative Coolers
Oil Cup | Grease Fitting | Shaft Size | A | B | C | D |
BJE12A | BJE12G | 3/4" | 2.169" | 1.094" | 4.625" | 3.328" |
BJE13A | BJE13G | 13/16" | 2.169" | 1.094" | 4.625" | 3.328" |
BJE14A | BJE14G | 7/8" | 2.169" | 1.094" | 4.625" | 3.328" |
BJE15A | BJE15G | 15/16" | 2.169" | 1.094" | 4.625" | 3.328" |
BJE16A | BJE16G | 1" | 2.169" | 1.094" | 4.625" | 3.328" |
BJE18A | BJE18G | 1 1/8" | 2.169" | 1.094" | 4.625" | 3.328" |
BJE19A | BJE19G | 1 3/16" | 2.169" | 1.094" | 4.625" | 3.328" |
BJE20A | BJE20G | 1 1/4" | 2.169" | 1.094" | 4.625" | 3.328" |
BKF18A | BKF18G | 1 1/8" | 2.686" | 1.343" | 5.5" | 3.875" |
BKF19A | BKF19G | 1 3/16" | 2.686" | 1.343" | 5.5" | 3.875" |
BKF20A | BKF20G | 1 1/4" | 2.686" | 1.343" | 5.5" | 3.875" |
BKF22A | BKF22G | 1 3/8" | 2.686" | 1.343" | 5.5" | 3.875" |
BKF24A | BKF24G | 1 1/2" | 2.686" | 1.343" | 5.5" | 3.875" |
Benefits of having Triangle become your pillow block bearing supplier include:
- Low Cost
- Low Maintenance: Triangle's pillow block bearings have a longer life-span because they are self-lubricating.
- Quieter Operation: Because these pillow block bearings are self-lubricating this results in a much smoother rotation with the shaft.
- Self-Aligning: Self-aligning bearings come in handy when your shaft is misaligned with the bearing. This will save you time and extra machine costs to fix your application.
If you are interested in any of Triangle's pillow block bearings, contact us today or call us at (920) 235-3710.
