Sintered Iron Bearing Ball 2 Bolt 2 Bolt Flange Bearing, 16 Gauge - 3/4"
with SAE30 Non-Detergent Oil, Center to Center 3.25", Overall Length 4", Bearing Width 0.75", Spherical Diameter 1.19" - Light Duty
Part #: FL9455
Sintered Iron Bearing Ball 2 Bolt 2 Bolt Flange Bearing, 16 Gauge - 3/4"
with SAE30 Non-Detergent Oil, Center to Center 3.25", Overall Length 4", Bearing Width 0.75", Spherical Diameter 1.19" - Light Duty
Part #: FL9455
Part #: FL9455
PRODUCT SPECIFICATIONS
- Triangle Series
- FL
- Type
- 2 Bolt Flange Bearing
- Shaft Size (Bore ID)
- 3/4"
- Inside Diameter Lower Tolerance
- 0.7545"
- Inside Diameter Upper Tolerance
- 0.756"
- Bearing Insert Type
- Bearing Ball without Bushing
- Bearing Ball Material
- Sintered Iron
- Bearing Spherical Diameter
- 1.19"
- Other Lubrication Apparatus Options Available
- Yes
- Type of Lubricant
- SAE30 Non-Detergent Oil
- Bearing Width
- 0.75"
- Number of Mount Holes
- 2
- Mount Material
- Steel
- Mount Material Gauge
- 16 Gauge
- Overall Length
- 4"
- Mount Width
- 1.5"
- Mount Hole Center to Center
- 3.25"
- Mount Hole Shape
- Round
- Mount Socket Diameter
- 1.188"
- Finish
- Pre-Plated Hot Dipped Galvanized Steel
- Other Mount Finish available
- Yes
- Tapped Hole Available
- No
- Bearing Fit Options Available
- Yes
- Strength
- Light Duty
Light-Duty Sintered Iron 2-Bolt Flange Bearings
Perfect for lighter loads and normal shaft speeds, Triangle's light-duty sintered iron 2-bolt flange bearings are used in multiple different mechanical equipment. Contact our team to find out if light-duty sintered iron bearing balls are perfect for your products.
*User Account Required | Create Account
| Triangle Series: | FL |
| Type: | 2 Bolt Flange Bearing |
| Shaft Size (Bore ID): | 3/4" |
| Inside Diameter Lower Tolerance: | 0.7545" |
| Inside Diameter Upper Tolerance: | 0.756" |
| Bearing Insert Type: | Bearing Ball without Bushing |
| Bushing Material: | Sintered Iron |
| Bearing Ball Material: | Sintered Iron |
| Bearing Spherical Diameter: | 1.19" |
| Type of Lubricant: | SAE30 Non-Detergent Oil |
| Bearing Width: | 0.75" |
| Number of Mount Holes: | 2 |
| Mount Material: | Steel |
| Overall Length: | 4" |
| Mount Hole Center to Center: | 3.25" |
| Mount Socket Diameter: | 1.188" |
| Strength: | Light Duty |
| Other Lubrication Apparatus Options Available: | Yes |
| Mount Material Gauge: | 16 Gauge |
| Mount Width: | 1.5" |
| Mount Hole Center to Center Type: | Imperial |
| Mount Hole Shape: | Round |
| Finish: | Pre-Plated Hot Dipped Galvanized Steel |
| Other Mount Finish available: | Yes |
| Tapped Hole Available: | No |
| Bearing Fit Options Available: | Yes |
| Min. Quantity for RFQ: | 1000 |
| With Cushion: | No |
| Bearing Mount Type With Bearing: | No |
Description
Light-Duty Sintered Iron 2-Bolt Flange Bearings
Perfect for lighter loads and normal shaft speeds, Triangle's light-duty sintered iron 2-bolt flange bearings are used in multiple different mechanical equipment. Contact our team to find out if light-duty sintered iron bearing balls are perfect for your products.
