    16 Items

    per page
    Set Descending Direction
    1. Offset Flange Mounted Bearing CD1408P Offset Flange Mounted Bearing CD1408P
      Add to Compare

      2 Bolt Offset Flange Mounted Bearing, 16 Gauge - 1/2"

      with SAE30 Non-Detergent Oil, Center to Center 1.5", Overall Length 3.735", Bearing Width 0.5", Spherical Diameter 1.002" Bolt Holes Mount Method
      Part #: CD1408P
      PRODUCT SPECIFICATIONS
      Triangle Series
      CD
      Type
      Offset Flange Mounted Bearing
      Shaft Size (Bore ID)
      1/2"
      Bearing Insert Type
      Bearing Ball without Bushing
      Bearing Ball Material
      Sintered Bronze
      Bearing Spherical Diameter
      1.002"
      Type of Lubricant
      SAE30 Non-Detergent Oil
      Bearing Width
      0.5"
      Number of Mount Holes
      2
      Mount Material
      Steel
      Mount Material Gauge
      16 Gauge
      Overall Length
      3.735"
      Mount Hole Center to Center
      1.5"
      Mount Socket Diameter
      1"
      View All Product Specs
    2. Offset Flange Mounted Bearing CD1406P Offset Flange Mounted Bearing CD1406P
      Add to Compare

      2 Bolt Offset Flange Mounted Bearing, 16 Gauge - 3/8"

      with SAE30 Non-Detergent Oil, Center to Center 1.5", Overall Length 3.735", Bearing Width 0.5", Spherical Diameter 1.002" Bolt Holes Mount Method
      Part #: CD1406P
      PRODUCT SPECIFICATIONS
      Triangle Series
      CD
      Type
      Offset Flange Mounted Bearing
      Shaft Size (Bore ID)
      3/8"
      Bearing Insert Type
      Bearing Ball without Bushing
      Bearing Ball Material
      Sintered Bronze
      Bearing Spherical Diameter
      1.002"
      Type of Lubricant
      SAE30 Non-Detergent Oil
      Bearing Width
      0.5"
      Number of Mount Holes
      2
      Mount Material
      Steel
      Mount Material Gauge
      16 Gauge
      Overall Length
      3.735"
      Mount Hole Center to Center
      1.5"
      Mount Socket Diameter
      1"
      View All Product Specs
    3. Offset Flange Mounted Bearing CDN8 Offset Flange Mounted Bearing CDN8
      Add to Compare

      Molded Nylon Bearing Ball 2 Bolt Offset Flange Mounted Bearing, 16 Gauge - 1/2"

      Center to Center 1.5", Overall Length 3.735", Bearing Width 0.5", Spherical Diameter 1.002" Bolt Holes Mount Method
      Part #: CDN8
      PRODUCT SPECIFICATIONS
      Triangle Series
      CD
      Type
      Offset Flange Mounted Bearing
      Shaft Size (Bore ID)
      1/2"
      Bearing Insert Type
      Bearing Ball without Bushing
      Bearing Ball Material
      Molded Nylon
      Bearing Spherical Diameter
      1.002"
      Bearing Width
      0.5"
      Number of Mount Holes
      2
      Mount Material
      Steel
      Mount Material Gauge
      16 Gauge
      Overall Length
      3.735"
      Mount Hole Center to Center
      1.5"
      Mount Socket Diameter
      1"
      View All Product Specs
    4. Offset Flange Mounted Bearing CDN4 Offset Flange Mounted Bearing CDN4
      Add to Compare

      Molded Nylon Bearing Ball 2 Bolt Offset Flange Mounted Bearing, 16 Gauge - 1/4"

      Center to Center 1.5", Overall Length 3.735", Bearing Width 0.5", Spherical Diameter 0.733" Bolt Holes Mount Method
      Part #: CDN4
      PRODUCT SPECIFICATIONS
      Triangle Series
      CD
      Type
      Offset Flange Mounted Bearing
      Shaft Size (Bore ID)
      1/4"
      Bearing Insert Type
      Bearing Ball without Bushing
      Bearing Ball Material
      Molded Nylon
      Bearing Spherical Diameter
      0.733"
      Bearing Width
      0.5"
      Number of Mount Holes
      2
      Mount Material
      Steel
      Mount Material Gauge
      16 Gauge
      Overall Length
      3.735"
      Mount Hole Center to Center
      1.5"
      Mount Socket Diameter
      1"
      View All Product Specs
    5. Offset Flange Mounted Bearing CDN12 Offset Flange Mounted Bearing CDN12
      Add to Compare

      Molded Nylon Bearing Ball 2 Bolt Offset Flange Mounted Bearing, 16 Gauge - 3/4"

      Center to Center 1.5", Overall Length 3.735", Bearing Width 0.5", Spherical Diameter 1.002" Bolt Holes Mount Method
      Part #: CDN12
      PRODUCT SPECIFICATIONS
      Triangle Series
      CD
      Type
      Offset Flange Mounted Bearing
      Shaft Size (Bore ID)
      3/4"
      Bearing Insert Type
      Bearing Ball without Bushing
      Bearing Ball Material
      Molded Nylon
      Bearing Spherical Diameter
      1.002"
      Bearing Width
      0.5"
      Number of Mount Holes
      2
      Mount Material
      Steel
      Mount Material Gauge
      16 Gauge
      Overall Length
      3.735"
      Mount Hole Center to Center
      1.5"
      Mount Socket Diameter
      1"
      View All Product Specs
    6. Offset Flange Mounted Bearing CDN6 Offset Flange Mounted Bearing CDN6
      Add to Compare

      Molded Nylon Bearing Ball 2 Bolt Offset Flange Mounted Bearing, 16 Gauge - 3/8"

      Center to Center 1.5", Overall Length 3.735", Bearing Width 0.5", Spherical Diameter 1.002" Bolt Holes Mount Method
      Part #: CDN6
      PRODUCT SPECIFICATIONS
      Triangle Series
      CD
      Type
      Offset Flange Mounted Bearing
      Shaft Size (Bore ID)
      3/8"
      Bearing Insert Type
      Bearing Ball without Bushing
      Bearing Ball Material
      Molded Nylon
      Bearing Spherical Diameter
      1.002"
      Bearing Width
      0.5"
      Number of Mount Holes
      2
      Mount Material
      Steel
      Mount Material Gauge
      16 Gauge
      Overall Length
      3.735"
      Mount Hole Center to Center
      1.5"
      Mount Socket Diameter
      1"
      View All Product Specs
    7. Offset Flange Mounted Bearing CDN5 Offset Flange Mounted Bearing CDN5
      Add to Compare

      Molded Nylon Bearing Ball 2 Bolt Offset Flange Mounted Bearing, 16 Gauge - 5/16"

      Center to Center 1.5", Overall Length 3.735", Bearing Width 0.5", Spherical Diameter 1" Bolt Holes Mount Method
      Part #: CDN5
      PRODUCT SPECIFICATIONS
      Triangle Series
      CD
      Type
      Offset Flange Mounted Bearing
      Shaft Size (Bore ID)
      5/16"
      Bearing Insert Type
      Bearing Ball without Bushing
      Bearing Ball Material
      Molded Nylon
      Bearing Spherical Diameter
      1"
      Bearing Width
      0.5"
      Number of Mount Holes
      2
      Mount Material
      Steel
      Mount Material Gauge
      16 Gauge
      Overall Length
      3.735"
      Mount Hole Center to Center
      1.5"
      Mount Socket Diameter
      1"
      View All Product Specs
    8. Offset Flange Mounted Bearing CDN10 Offset Flange Mounted Bearing CDN10
      Add to Compare

      Molded Nylon Bearing Ball 2 Bolt Offset Flange Mounted Bearing, 16 Gauge - 5/8"

      Center to Center 1.5", Overall Length 3.735", Bearing Width 0.5", Spherical Diameter 1.002" Bolt Holes Mount Method
      Part #: CDN10
      PRODUCT SPECIFICATIONS
      Triangle Series
      CD
      Type
      Offset Flange Mounted Bearing
      Shaft Size (Bore ID)
      5/8"
      Bearing Insert Type
      Bearing Ball without Bushing
      Bearing Ball Material
      Molded Nylon
      Bearing Spherical Diameter
      1.002"
      Bearing Width
      0.5"
      Number of Mount Holes
      2
      Mount Material
      Steel
      Mount Material Gauge
      16 Gauge
      Overall Length
      3.735"
      Mount Hole Center to Center
      1.5"
      Mount Socket Diameter
      1"
      View All Product Specs
    9. Offset Flange Mounted Bearing CDN7 Offset Flange Mounted Bearing CDN7
      Add to Compare

      Molded Nylon Bearing Ball 2 Bolt Offset Flange Mounted Bearing, 16 Gauge - 7/16"

      Center to Center 1.5", Overall Length 3.735", Bearing Width 0.5", Spherical Diameter 1.002" Bolt Holes Mount Method
      Part #: CDN7
      PRODUCT SPECIFICATIONS
      Triangle Series
      CD
      Type
      Offset Flange Mounted Bearing
      Shaft Size (Bore ID)
      7/16"
      Bearing Insert Type
      Bearing Ball without Bushing
      Bearing Ball Material
      Molded Nylon
      Bearing Spherical Diameter
      1.002"
      Bearing Width
      0.5"
      Number of Mount Holes
      2
      Mount Material
      Steel
      Mount Material Gauge
      16 Gauge
      Overall Length
      3.735"
      Mount Hole Center to Center
      1.5"
      Mount Socket Diameter
      1"
      View All Product Specs
    10. Offset Flange Mounted Bearing CD1410P Offset Flange Mounted Bearing CD1410P
      Add to Compare

      Sintered Bronze Bearing Ball 2 Bolt Offset Flange Mounted Bearing, 16 Gauge - 5/8"

      with SAE30 Non-Detergent Oil, Center to Center 1.5", Overall Length 3.735", Bearing Width 0.5", Spherical Diameter 1.002" Bolt Holes Mount Method
      Part #: CD1410P
      PRODUCT SPECIFICATIONS
      Triangle Series
      CD
      Type
      Offset Flange Mounted Bearing
      Shaft Size (Bore ID)
      5/8"
      Bearing Insert Type
      Bearing Ball without Bushing
      Bearing Ball Material
      Sintered Bronze
      Bearing Spherical Diameter
      1.002"
      Type of Lubricant
      SAE30 Non-Detergent Oil
      Bearing Width
      0.5"
      Number of Mount Holes
      2
      Mount Material
      Steel
      Mount Material Gauge
      16 Gauge
      Overall Length
      3.735"
      Mount Hole Center to Center
      1.5"
      Mount Socket Diameter
      1"
      View All Product Specs
    11. Offset Flange Mounted Bearing CD14M10 Offset Flange Mounted Bearing CD14M10
      Add to Compare

      Sintered Bronze Bearing Ball 2 Bolt Offset Flange Mounted Bearing, 16 Gauge - 10 mm

      with SAE30 Non-Detergent Oil, Center to Center 1.5", Overall Length 3.735", Bearing Width 0.5", Spherical Diameter 1.002" Bolt Holes Mount Method
      Part #: CD14M10
      PRODUCT SPECIFICATIONS
      Triangle Series
      CD
      Type
      Offset Flange Mounted Bearing
      Shaft Size (Bore ID)
      10 mm
      Bearing Insert Type
      Bearing Ball without Bushing
      Bearing Ball Material
      Sintered Bronze
      Bearing Spherical Diameter
      1.002"
      Type of Lubricant
      SAE30 Non-Detergent Oil
      Bearing Width
      0.5"
      Number of Mount Holes
      2
      Mount Material
      Steel
      Mount Material Gauge
      16 Gauge
      Overall Length
      3.735"
      Mount Hole Center to Center
      1.5"
      Mount Socket Diameter
      1"
      View All Product Specs
    12. Offset Flange Mounted Bearing CD14M12 Offset Flange Mounted Bearing CD14M12
      Add to Compare

      Sintered Bronze Bearing Ball 2 Bolt Offset Flange Mounted Bearing, 16 Gauge - 12 mm

      with SAE30 Non-Detergent Oil, Center to Center 1.5", Overall Length 3.735", Bearing Width 0.5", Spherical Diameter 1.002" Bolt Holes Mount Method
      Part #: CD14M12
      PRODUCT SPECIFICATIONS
      Triangle Series
      CD
      Type
      Offset Flange Mounted Bearing
      Shaft Size (Bore ID)
      12 mm
      Bearing Insert Type
      Bearing Ball without Bushing
      Bearing Ball Material
      Sintered Bronze
      Bearing Spherical Diameter
      1.002"
      Type of Lubricant
      SAE30 Non-Detergent Oil
      Bearing Width
      0.5"
      Number of Mount Holes
      2
      Mount Material
      Steel
      Mount Material Gauge
      16 Gauge
      Overall Length
      3.735"
      Mount Hole Center to Center
      1.5"
      Mount Socket Diameter
      1"
      View All Product Specs
    13. Offset Flange Mounted Bearing CD14M16 Offset Flange Mounted Bearing CD14M16
      Add to Compare

      Sintered Bronze Bearing Ball 2 Bolt Offset Flange Mounted Bearing, 16 Gauge - 16 mm

      with SAE30 Non-Detergent Oil, Center to Center 1.5", Overall Length 3.735", Bearing Width 0.5", Spherical Diameter 1.002" Bolt Holes Mount Method
      Part #: CD14M16
      PRODUCT SPECIFICATIONS
      Triangle Series
      CD
      Type
      Offset Flange Mounted Bearing
      Shaft Size (Bore ID)
      16 mm
      Bearing Insert Type
      Bearing Ball without Bushing
      Bearing Ball Material
      Sintered Bronze
      Bearing Spherical Diameter
      1.002"
      Type of Lubricant
      SAE30 Non-Detergent Oil
      Bearing Width
      0.5"
      Number of Mount Holes
      2
      Mount Material
      Steel
      Mount Material Gauge
      16 Gauge
      Overall Length
      3.735"
      Mount Hole Center to Center
      1.5"
      Mount Socket Diameter
      1"
      View All Product Specs
    14. Offset Flange Mounted Bearing CD1508P Offset Flange Mounted Bearing CD1508P
      Add to Compare

      Sintered Iron Bearing Ball 2 Bolt Offset Flange Mounted Bearing, 16 Gauge - 1/2"

      with SAE30 Non-Detergent Oil, Center to Center 1.5", Overall Length 3.735", Bearing Width 0.5", Spherical Diameter 1.002" Bolt Holes Mount Method
      Part #: CD1508P
      PRODUCT SPECIFICATIONS
      Triangle Series
      CD
      Type
      Offset Flange Mounted Bearing
      Shaft Size (Bore ID)
      1/2"
      Bearing Insert Type
      Bearing Ball without Bushing
      Bearing Ball Material
      Sintered Iron
      Bearing Spherical Diameter
      1.002"
      Type of Lubricant
      SAE30 Non-Detergent Oil
      Bearing Width
      0.5"
      Number of Mount Holes
      2
      Mount Material
      Steel
      Mount Material Gauge
      16 Gauge
      Overall Length
      3.735"
      Mount Hole Center to Center
      1.5"
      Mount Socket Diameter
      1"
      View All Product Specs
    15. Offset Flange Mounted Bearing CD1512P Offset Flange Mounted Bearing CD1512P
      Add to Compare

      Sintered Iron Bearing Ball 2 Bolt Offset Flange Mounted Bearing, 16 Gauge - 3/4"

      with SAE30 Non-Detergent Oil, Center to Center 1.5", Overall Length 3.735", Bearing Width 0.5", Spherical Diameter 1.002" Bolt Holes Mount Method
      Part #: CD1512P
      PRODUCT SPECIFICATIONS
      Triangle Series
      CD
      Type
      Offset Flange Mounted Bearing
      Shaft Size (Bore ID)
      3/4"
      Bearing Insert Type
      Bearing Ball without Bushing
      Bearing Ball Material
      Sintered Iron
      Bearing Spherical Diameter
      1.002"
      Type of Lubricant
      SAE30 Non-Detergent Oil
      Bearing Width
      0.5"
      Number of Mount Holes
      2
      Mount Material
      Steel
      Mount Material Gauge
      16 Gauge
      Overall Length
      3.735"
      Mount Hole Center to Center
      1.5"
      Mount Socket Diameter
      1"
      View All Product Specs
    16. Offset Flange Mounted Bearing CD1510P Offset Flange Mounted Bearing CD1510P
      Add to Compare

      Sintered Iron Bearing Ball 2 Bolt Offset Flange Mounted Bearing, 16 Gauge - 5/8"

      with SAE30 Non-Detergent Oil, Center to Center 1.5", Overall Length 3.735", Bearing Width 0.5", Spherical Diameter 1.002" Bolt Holes Mount Method
      Part #: CD1510P
      PRODUCT SPECIFICATIONS
      Triangle Series
      CD
      Type
      Offset Flange Mounted Bearing
      Shaft Size (Bore ID)
      5/8"
      Bearing Insert Type
      Bearing Ball without Bushing
      Bearing Ball Material
      Sintered Iron
      Bearing Spherical Diameter
      1.002"
      Type of Lubricant
      SAE30 Non-Detergent Oil
      Bearing Width
      0.5"
      Number of Mount Holes
      2
      Mount Material
      Steel
      Mount Material Gauge
      16 Gauge
      Overall Length
      3.735"
      Mount Hole Center to Center
      1.5"
      Mount Socket Diameter
      1"
      View All Product Specs

    17. The part numbers displayed on our website are just a small portion of items we manufacture. Contact us today so we can help you find your ideal solution. We offer various bore IDs, material options, mounts and more!

      View All Product Specs
      View All Product Specs

    Offset Flange Bearings

    FILTER RESULTS
    FILTER

    Shaft Size (Bore ID)

      Shaft Size / Bore Size

    SHAFT SIZE

     “Shaft size” is the measurement of shaft for your application. It can also be similar to the measurement of the “Bore” or “Inside Diameter” of your bearing. A slightly loose shaft fit is desirable for most applications.

    For linkages and rod ends, shafts are not typically used but it refers to the measurement of the bore ID whether you are using a bolt or screw through the inside diameter of your rod end. See image below.
    Apply

    Bearing Spherical
    Diameter

    Apply

    Bearing Ball
    Material

      How to Select a Material

    SINTERED BRONZE

    Type of
    Lubricant

      How to Choose Type of Lubricant

    TYPE OF LUBRICANT



    GREASE LUBRICATION

    Bearings with grease fittings are NOT factory lubricated. Grease should be applied with a pressure gun at the time of installation, filling the ball unit and bearing until grease appears at the shaft surface.

    Grease for a lubrication is recommended for applications with lower speeds and loads. Because the grease restricts contaminants from entering it is preferred for dusty and dirty applications.



    PLASTIC E LUBE

    Gulf Plastic Petroleum “E” feeds slowly through the bushing by capillary action, replacing dissipated lubricant. Factory-lubricated ball units may be closed balls or equipped with removable plugs for relubrication.



    SAE 30 NON-DETERGENT OIL

    FOR BEARING BALL WITH BUSHING

    Triangle Steel Bearing Ball Units have large oil retaining felts for substantial lubricant capacity. Once the bearing is in use and the ball and felt saturated with oil, long bearing life may be expected under proper operating conditions. The standard oil supplied is a good grade of industrial mineral oil, NON-DETERGENT, SAE 30 viscosity. Bearing use at elevated or very low temperatures may require oil of different viscosity. Triangle recommends relubrication of bearings at the time of installation even though a full supply of oil is provided at the factory. Conditions encountered during shipping and storage may cause some oil loss.



    FOR SINTERED BEARINGS

    Triangle’s sintered bearings are oil impregnated with SAE30-Non-Detergent oil. These bearings are porous which allows for the bearing to be constantly re-lubricated while being used.



    BEARINGS WITH SPECIAL LUBRICANT

    Triangle is not limited to the lubrication methods described above. If you require a special lubricant, please contact us. We will be happy to discuss that requirement with you.
    PRODUCTS

     (

    )

    Select and compare up to 4 products.
    Select and compare up to 4 products.
    Copyright © 2024 Triangle Manufacturing Company. All rights reserved.
